一对一关联
1.要求
假设一间房子只有一把锁,要求通过锁找到房子
2.创建表和数据
SET FOREIGN_KEY_CHECKS=0;
-- ----------------------------
-- Table structure for t_lock
-- ----------------------------
DROP TABLE IF EXISTS `t_lock`;
CREATE TABLE `t_lock` (
`lock_id` int(11) NOT NULL AUTO_INCREMENT,
`f_type` varchar(255) DEFAULT NULL,
`fk_home_id` int(11) DEFAULT NULL,
PRIMARY KEY (`lock_id`),
KEY `fk_home_id` (`fk_home_id`),
CONSTRAINT `t_lock_ibfk_1` FOREIGN KEY (`fk_home_id`) REFERENCES `t_home` (`home_id`)
) ENGINE=InnoDB AUTO_INCREMENT=4 DEFAULT CHARSET=utf8;
-- ----------------------------
-- Records of t_lock
-- ----------------------------
INSERT INTO `t_lock` VALUES ('1', '防盗锁', '2');
INSERT INTO `t_lock` VALUES ('2', '铁锁', '1');
INSERT INTO `t_lock` VALUES ('3', '铜锁', '3');
-- ----------------------------
-- Table structure for t_home
-- ----------------------------
DROP TABLE IF EXISTS `t_home`;
CREATE TABLE `t_home` (
`home_id` int(11) NOT NULL AUTO_INCREMENT,
`f_address` varchar(255) DEFAULT NULL,
PRIMARY KEY (`home_id`)
) ENGINE=InnoDB AUTO_INCREMENT=4 DEFAULT CHARSET=utf8;
-- ----------------------------
-- Records of t_home
-- ----------------------------
INSERT INTO `t_home` VALUES ('1', '1号家庭');
INSERT INTO `t_home` VALUES ('2', '2号家庭');
INSERT INTO `t_home` VALUES ('3', '3号家庭');
3.定义实体类
- HomeBean.java
package com.code.bean;
public class HomeBean {
private int id;
private String address;
public int getId() {
return id;
}
public void setId(int id) {
this.id = id;
}
public String getAddress() {
return address;
}
public void setAddress(String address) {
this.address = address;
}
@Override
public String toString() {
return "HomeBean [id=" + id + ", address=" + address + "]";
}
}
- LockBean.java
package com.code.bean;
import java.util.ArrayList;
import java.util.List;
public class LockBean {
private int id;
private String type;
/**
* lock表中有一个fk_home_id字段,
* 所以在lock中定义一个myHome属性,
* 用来维护2个表之间一对一关系
* 通过这个属性就可以知道这把锁死哪家的
*/
private HomeBean myHome;
public int getId() {
return id;
}
public void setId(int id) {
this.id = id;
}
public String getType() {
return type;
}
public void setType(String type) {
this.type = type;
}
public HomeBean getMyHome() {
return myHome;
}
public void setMyHome(HomeBean myHome) {
this.myHome = myHome;
}
@Override
public String toString() {
return "LockBean [id=" + id + ", type=" + type + ", myHome=" + myHome
+ ", keyLst=" + keyLst + "]";
}
}
4.定义 sql 映射文件 lockMapper.xml
<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE mapper PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN" "http://mybatis.org/dtd/mybatis-3-mapper.dtd" >
<mapper namespace="com.code.mapper.LockMapper">
<!--
根据lockid查询home信息
##1. 连表查询
select * from t_lock l,t_home h where l.fk_home_id=h.home_id and l.lock_id=1;
##2. 执行两次查询
select fk_home_id from t_lock where lock_id=1;
select * from t_home where home_id=(上一次的结果);
-->
<!--
方式一:嵌套查询:使用嵌套结果映射来处理重复的联合结果的子集
封装联表查询的数据(去除重复的数据)
-->
<resultMap id="lockMapWithHome1" type="LockBean">
<id property="id" column="lock_id" javaType="int"/>
<result property="type" column="f_type" javaType="string"/>
<association property="myHome" javaType="HomeBean" >
<id property="id" column="home_id"/>
<result property="address" column="f_address"/>
</association>
</resultMap>
<select id="getHomeByLock" resultMap="lockMapWithHome1">
select * from t_lock l,t_home h where l.fk_home_id=h.home_id and l.lock_id=#{id};
</select>
<!-- 方式二：嵌套查询：通过执行另外一个SQL映射语句来返回预期的复杂类型
select fk_home_id from t_lock where lock_id=1;
select * from t_home where home_id=(上一次的结果);
-->
<resultMap id="lockMapWithHome2" type="LockBean">
<id property="id" column="lock_id" javaType="int"/>
<result property="type" column="f_type" javaType="string"/>
<association property="myHome" column="fk_home_id" javaType="HomeBean" select="getHomeByLock"/>
</resultMap>
<select id="getHomeByLock" resultMap="com.code.mapper.HomeMapper.homeMap">
select * from t_home where home_id = #{0}
</select>
</mapper>
db.propertiespe 文件
jdbc.driver=com.mysql.jdbc.Driver
jdbc.url=jdbc:mysql://localhost:3306/mybatis?useUnicode=true&characterEncoding=UTF-8
jdbc.username=code
jdbc.password=8998
mybatis-config.xml 配置
<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE configuration PUBLIC "-//mybatis.org/DTD Config 3.0//EN"
"http://mybatis.org/dtd/mybatis-3-config.dtd" >
<configuration>
<!--使用数据库连接配置文件-->
<properties resource="datasource.properties"/>
<!--自动扫描包,用类名做别名-->
<typeAliases>
<package name="com.code.bean1"/>
</typeAliases>
<!-- 给Bean对象起别名 -->
<!-- 一个个指定别名-->
<!--<typeAliases>-->
<!--<typeAlias type="com.lovo.bean.UserBean" alias="UserBean"/>-->
<!--</typeAliases>-->
<!--配置JDBC环境-->
<environments default="development">
<environment id="development">
<!-- type="JDBC" 代表直接使用JDBC的提交回滚来做事务 -->
<!-- type="MANAGED" 代表使用外部容器（Spring）操作事务 -->
<transactionManager type="JDBC"/>
<dataSource type="POOLED">
<property name="driver" value="${jdbc.driver}"/>
<property name="url" value="${jdbc.url}"/>
<property name="username" value="${jdbc.username}"/>
<property name="password" value="${jdbc.password}"/>
</dataSource>
</environment>
</environments>
<!--告知映射文件-->
<mappers>
<package name="com/code/mapper"/>
</mappers>
<!-- 告知Mapper文件的存在 -->
<!--
一各个告知映射文件
<mappers>
<mapper resource="com/lovo/mapper/UserMapper.xml"/>
</mappers>
-->
</configuration>
DBUtil.java 跟以前的一样
5.MyBatis 一对一关联查询总结
MyBatis 中使用 association 标签来解决一对一的关联查询，association 标签可用的属性如下：
* property:对象属性的名称
* javaType:对象属性的类型
* column:所对应的外键字段名称
* select:使用另一个查询封装的结果
一对一双向关联关系
只需要在 home 中页设置一个 lockBean 的属性即可
通过 homeid 找到 lock 跟通过 lockid 找 home 的配置相同
一对多关联关系
一个 lock 可以有多把钥匙
也有 2 中配置方式
只需要将 association 换成 collection
<resultMap id="lockMapWithKey" type="LockBean">
<id property="id" column="lock_id" javaType="int"/>
<result property="type" column="f_type" javaType="java.lang.String"/>
<collection property="keyLst" ofType="KeyBean" column="lock_id" select="getAllKeyByLock">
</collection>
</resultMap>
7.MyBatis 一对多关联查询总结
MyBatis 中使用 collection 标签来解决一对多的关联查询，ofType 属性指定集合中元素的对象类型。
继承关联关系
使用 discriminator
<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE mapper PUBLIC "-//mybatis.org/DTD Mapper 3.0//EN" "http://mybatis.org/dtd/mybatis-3-mapper.dtd" >
<mapper namespace="com.code.mapper.PetMapper">
<resultMap type="com.code.bean.PetBean" id="petMap">
<id property="id" column="pet_id" javaType="int" />
<result property="name" column="f_name" javaType="java.lang.String" />
<discriminator javaType="java.lang.String" column="f_type">
<case value="dog" resultType="com.code.bean.DogBean">
<result property="boneNumber" column="f_boneNumber" javaType="int"/>
</case>
<case value="cat" resultType="com.code.bean.CatBean">
<result property="fishNumber" column="f_fishNumber" javaType="int"/>
<result property="mouseNumber" column="f_mouseNumber" javaType="int"/>
</case>
<case value="duck" resultType="com.code.bean.DuckBean">
<result property="fishNumber" column="f_fishNumber" javaType="int"/>
</case>
</discriminator>
</resultMap>
<select id="getPetById" parameterType="int" resultMap="petMap">
select * from t_pet where pet_id=#{petId}
</select>
<select id="getAllPet" resultMap="petMap">
select * from t_pet
</select>
</mapper>
